| 输出功率 | 电流 | 柴油机型号 | 缸数 | 缸径 | 行程 | 排气量（L） | 燃油消耗率 （g/kw.h） | 机组尺寸mm （L×W×H） | 机组重量 （kg） | |
| KW | KVA | (A) | (mm) | (mm) | ||||||
| 18 | 22.5 | 32.4 | YC2108D | 2 | 108 | 120 | 2.20 | ≤225 | 1700×700×1000 | 650 |
| 24 | 30 | 43.2 | YC2115D | 2 | 115 | 120 | 2.49 | ≤220 | 1700×700×1000 | 650 |
| 30 | 37.5 | 54 | YC2115ZD | 2 | 108 | 115 | 2.11 | ≤205 | 1700×750×1000 | 900 |
| 40 | 50 | 72 | YC4D60-D21 | 4 | 108 | 115 | 4.21 | ≤205 | 1800×750V1200 | 920 |
| 50 | 62.5 | 90 | YC4D85Z-D20 | 4 | 108 | 115 | 4.21 | ≤200 | 1800×750×1200 | 950 |
| 60 | 75 | 108 | YC4D90Z-D20 | 4 | 108 | 115 | 4.21 | ≤200 | 2000×800×1250 | 1100 |
| 64 | 80 | 115.2 | YC4A100Z-D20 | 4 | 108 | 125 | 4.58 | ≤200 | 2250×800×1300 | 1200 |
| 90 | 112.5 | 162 | YC6B135Z-D20 | 6 | 108 | 125 | 6.87 | ≤202 | 2250×800×1300 | 1300 |
| 100 | 125 | 180 | YC6B155L-D21 | 6 | 108 | 125 | 6.87 | ≤200 | 2300×800×1300 | 1500 |
| 120 | 150 | 216 | YC6B180L-D20 | 6 | 108 | 132 | 7.26 | ≤192 | 2300×830×1300 | 1600 |
| 132 | 165 | 237.6 | YC6A200L-D20 | 6 | 108 | 132 | 7.26 | ≤195 | 2300×830×1300 | 1700 |
| 150 | 187.5 | 270 | YC6A230L-D20 | 6 | 108 | 132 | 7.26 | ≤192 | 2400×970×1500 | 2100 |
| 160 | 200 | 288 | YC6G245L-D20 | 6 | 112 | 132 | 7.80 | ≤195 | 2500×970×1500 | 2300 |
| 200 | 250 | 360 | YC6M350L-D20 | 6 | 120 | 145 | 9.84 | ≤197 | 3100×1050×1750 | 2750 |
| 250 | 312.5 | 450 | YC6MK420L-D20 | 6 | 123 | 145 | 10.34 | ≤195 | 3200×1150×1750 | 3000 |
| 280 | 350 | 504 | YC6MK420L-D20 | 6 | 123 | 145 | 10.34 | ≤195 | 3200×1150×1750 | 3000 |
| 300 | 375 | 540 | YC6MJ480L-D20 | 6 | 131 | 145 | 11.73 | ≤197 | 3200×1200×1750 | 3100 |
| 320 | 400 | 576 | YC6MJ480L-D20 | 6 | 131 | 145 | 11.73 | ≤195 | 3200×1200×1750 | 3100 |
| 350 | 437.5 | 630 | YC6T550L-D21 | 6 | 145 | 165 | 16.35 | ≤195 | 3300×1250×1850 | 3500 |
| 400 | 500 | 720 | YC6T600L-D22 | 6 | 145 | 165 | 16.35 | ≤195 | 3400×1500×1970 | 3900 |
| 440 | 550 | 792 | YC6T660L-D20 | 6 | 145 | 165 | 16.35 | ≤195 | 3500×1500×1970 | 4000 |
| 460 | 575 | 828 | YC6T700L-D20 | 6 | 145 | 165 | 16.35 | ≤195 | 3500×1500×1950 | 4000 |
| 500 | 625 | 900 | YC6TD780L-D20 | 6 | 145 | 165 | 16.35 | ≤195 | 3600×1600×1950 | 4100 |
| 550 | 687.5 | 990 | YC6TD840L-D20 | 6 | 200 | 210 | 39.58 | ≤195 | 3650×1600×2000 | 4200 |
| 650 | 812.5 | 1170 | YC6C1020L-D20 | 6 | 200 | 210 | 39.58 | ≤195 | 4000×1500×2100 | 5500 |
| 700 | 875 | 1260 | YC6C1070L-D20 | 6 | 200 | 210 | 39.58 | ≤195 | 4200×1650×2100 | 5800 |
| 800 | 1000 | 1440 | YC6C1220L-D20 | 6 | 200 | 210 | 39.58 | ≤195 | 4300×1750×2200 | 6100 |
| 880 | 1100 | 1584 | YC6C1320L-D20 | 6 | 200 | 210 | 39.58 | ≤195 | 5200×2150×2500 | 7500 |
| 1000 | 1250 | 1800 | YC12VC1680L-D20 | 12 | 200 | 210 | 79.17 | ≤195 | 5000×2000×2500 | 9800 |
| 1100 | 1375 | 1980 | YC12VC1680L-D20 | 12 | 200 | 210 | 79.17 | ≤195 | 5100×2080×2500 | 9900 |
| 1200 | 1500 | 2160 | YC12VC2070L-D20 | 12 | 200 | 210 | 79.17 | ≤195 | 5300×2080×2500 | 10000 |
| 1320 | 1650 | 2376 | YC12VC2070L-D20 | 12 | 200 | 210 | 79.17 | ≤195 | 5500×2180×2550 | 11000 |
| 1500 | 1875 | 2700 | YC12VC2270L-D20 | 12 | 200 | 210 | 79.17 | ≤195 | 5600×2280×2600 | 12000 |
| 1600 | 2000 | 2880 | YC12VC2510L-D20 | 12 | 200 | 210 | 79.17 | ≤195 | 5600×2280×2600 | 12500 |
