| 机组型号 | 输出功率(kw) | 电流(A) | 柴油机型号 | 缸数 | 缸径×行程 （mm） | 排气量 (L) | 燃油消耗率 （ g/kw.h） | 机组尺寸mm （ L×W×H） | 机组重量 （kg） | |
| KW | KVA | |||||||||
| P-7GF | 7 | 8.75 | 12.6 | 403A-11G1 | 3 | 77×87 | 0.99 | 248 | 1200×700×1100 | 500 |
| P-8GF | 8 | 10 | 14.4 | 403D-11G | 3 | 77×81 | 1.13 | 252 | 1200×700×1100 | 300 |
| P-10GF | 10 | 12.5 | 18 | 403A-15G1 | 3 | 84×90 | 1.62 | 264 | 1250×700*1100 | 350 |
| P-11GF | 11 | 13.75 | 19.8 | 403D-15G | 3 | 84×90 | 1.49 | 247 | 1250×700×1100 | 350 |
| P-12GF | 12 | 15 | 21.6 | 403A-15G2 | 3 | 84×90 | 1.49 | 264 | 1250×700×1100 | 350 |
| P-16GF | 16 | 20 | 28.8 | 404A-22G1 | 4 | 84×100 | 2.2 | 237 | 1500×730×1300 | 500 |
| P-16GF | 16 | 20 | 28.8 | 404D-22G | 4 | 84×100 | 2.2 | 245 | 1500×730×1300 | 500 |
| P-24GF | 24 | 30 | 43.2 | 1103A-33G | 3 | 105×127 | 3.3 | 211 | 1770×750×1600 | 800 |
| P-36GF | 36 | 45 | 64.8 | 1103A-33TG1 | 3 | 105×127 | 3.3 | 211 | 2050×750×1600 | 920 |
| P-50GF | 50 | 62.5 | 90 | 1104A-44TG1 | 4 | 105×127 | 4.4 | 208 | 2250×750×1600 | 1100 |
| P-50GF | 50 | 62.5 | 90 | 1103A-33TG2 | 3 | 105×127 | 3.3 | 215 | 2200×750×1600 | 1050 |
| P-64GF | 64 | 80 | 115.2 | 1104A-44TG2 | 4 | 105×127 | 4.4 | 208 | 2300×750×1600 | 1150 |
| P-64GF | 64 | 80 | 115.2 | 1104C-44TAG1 | 4 | 100×127 | 4.4 | 205 | 2480×760×1600 | 1250 |
| P-80GF | 80 | 100 | 144 | 1104C-44TAG2 | 4 | 100×127 | 4.4 | 208 | 2480×760×1600 | 1250 |
| P-110GF | 110 | 137.5 | 198 | 1106A-70TG1 | 6 | 100×120 | 7.01 | 199 | 2480×760×1600 | 1250 |
| P-120GF | 120 | 150 | 216 | 1106A-70TAG2 | 6 | 105×135 | 7.01 | 208 | 2650×760×1600 | 1450 |
| P-140GF | 140 | 175 | 252 | 1106A-70TAG3 | 6 | 105×135 | 7.01 | 206 | 2700×900×1600 | 1700 |
| P-160GF | 160 | 200 | 288 | 1106A-70TAG4 | 6 | 105×135 | 7.01 | 220 | 3000×1000×1700 | 2100 |
| P-180GF | 180 | 225 | 324 | 1306A-E87TAG4 | 6 | 116×136 | 8.7 | 206 | 3000×1000×1700 | 2100 |
| P-180GF | 180 | 225 | 324 | 1506A-E88TAG2 | 6 | 112×149 | 8.8 | 200 | 3000×1000×1700 | 2100 |
| P-200GF | 200 | 250 | 360 | 1306A-E87TAG6 | 6 | 116×136 | 8.7 | 198 | 3100×1000×1700 | 2150 |
| P-200GF | 200 | 250 | 360 | 1506A-E88TAG3 | 6 | 112×149 | 8.8 | 200 | 3100×1000×1700 | 2150 |
| P-220GF | 220 | 275 | 396 | 1606A-E93TAG4 | 6 | 116×136 | 8.7 | 201 | 3100×1000×1700 | 2150 |
| P-220GF | 220 | 275 | 396 | 1506A-E88TAG4 | 6 | 112×149 | 8.8 | 198 | 3100×1000×1700 | 2150 |
| P-240GF | 240 | 300 | 432 | 1606A-E93TAG5 | 6 | 116×136 | 12.5 | 216 | 3100×1000×1700 | 2150 |
| P-240GF | 240 | 300 | 432 | 1506A-E88TAG5 | 6 | 112×149 | 8.8 | 198 | 3100×1000×1700 | 2150 |
| P-280GF | 280 | 350 | 504 | 2206C-E13TAG2 | 6 | 130×157 | 12.5 | 209 | 3600×1200×2000 | 3200 |
| P-320GF | 320 | 400 | 576 | 2206C-E13TAG3 | 6 | 130×157 | 12.5 | 206 | 3650×1200×2000 | 3300 |
| P-360GF | 360 | 450 | 648 | 2506C-E15TAG1 | 6 | 137×171 | 15.2 | 211 | 4000×1200×2100 | 3700 |
| P-400GF | 400 | 500 | 720 | 2506C-E15TAG2 | 6 | 137×171 | 15.2 | 211 | 4050×1200×2100 | 3760 |
| P-480GF | 480 | 600 | 864 | 2806C-E18TAG1A | 6 | 145×183 | 18.1 | 216 | 4100×1600×2200 | 4600 |
| P-520GF | 520 | 650 | 936 | 2806A-E18TAG2 | 6 | 145×183 | 18.1 | 202 | 4200×1600×2200 | 4800 |
| P-600GF | 600 | 750 | 1080 | 4006-23TAG2A | 6 | 160×190 | 22.9 | 209 | 4500×1800×2300 | 5500 |
| P-640GF | 640 | 800 | 1152 | 4006-23TAG3A | 6 | 160×190 | 22.9 | 209 | 4600×1800×2300 | 6000 |
| P-720GF | 720 | 900 | 1296 | 4008TAG1A | 8 | 160×190 | 30.5 | 206 | 4800×2100×2500 | 7700 |
| P-800GF | 800 | 1000 | 1440 | 4008TAG2A | 8 | 160×190 | 30.5 | 206 | 4900×2100×2500 | 8000 |
| P-1000GF | 1000 | 1250 | 1800 | 4012-46TWG2A | 12 | 160×190 | 45.8 | 212 | 5300×2200×2600 | 10000 |
| P-1100GF | 1100 | 1375 | 1980 | 4012-46TWG3A | 12 | 160×190 | 45.8 | 212 | 5300×2200×2600 | 10000 |
| P-1200GF | 1200 | 1500 | 2160 | 4012-46TAG2A | 12 | 160×190 | 45.8 | 212 | 5400×2200×2600 | 11000 |
| P-1360GF | 1360 | 1700 | 2448 | 4012-46TAG3A | 12 | 160×190 | 45.8 | 212 | 5500×2200×2600 | 12000 |
| P-1480GF | 1480 | 1850 | 2664 | 4016TAG1A | 16 | 160×190 | 61.1 | 205 | 5700×2800×3100 | 13500 |
| P-1600GF | 1600 | 2000 | 2880 | 4016TAG2A | 16 | 160×190 | 61.1 | 208 | 5800×2800×3100 | 14000 |
| P-1800GF | 1800 | 2250 | 3240 | 4016-61TRG3 | 16 | 160×190 | 61.1 | 205 | 5900×2800×3100 | 15700 |
